Product Details:
|
| Inverter: | ABB/SIEMENS | Type: | WPC Profile Production Line |
|---|---|---|---|
| Condition: | NEW | Screw Design: | Double Screw |
| Automatic Grade: | Automatic | After-sales Service Provided: | Engineers Available To Service |
| High Light: | Plastic Profile Extrusion Machine,Plastic Profile Extruder |
||
WPC Cabinet Plastic Profile Extrusion Machinery , WPC Plastic Profile Extruder
Quick detail:
1 . process type:extruding machine
2 . Automatic Grade : Automatic
3 . screw design:double screw
Description:
1. Model SJZ series conical twin screw extruder is a kind of special equipment for extruding PVC compound. With different kinds of molds and auxiliary machines, it can produce all sorts of PVC plastic pipe, profile, plate material, sheet material, bar material and granulation.
2. The conical twin screws have applied oil cooling system. Barrel is cooled by special wind cooling system.
3. The conical twin screw extruder system has applied special computer control. According to customers requirements, most reasonable structure of conical twin screw can be made so as to achieve best plasticity performance and material quality.
4. The conical twin screw is made by high precision special digital screw miller; extruding property can be highly harmonized. It has firstly introduced advanced technique of producing screw with variable pitch and depth, so that the material can be more softly sheared and cut.
5. The distribution box is specially designed, pull force bearing is fully imported, and the drive life span can be prolonged. It can bear larger extruding pressure.
6. The electrical system has mainly applied imported parts, it has multiple alarm system, and there are few problems which can be easily eliminated. The cooling system has applied special design, heat emission area is enlarged, the cooling is rapid, and temperature control tolerance can be ± 1degree.
Applications:
1 . The conical twin screw is made by high precision special digital screw miller; extruding property can be
highly harmonized. It has firstly introduced advanced technique of producing screw with variable pitch and
depth, so that the material can be more softly sheared and cut.
2 . The conical twin screws have applied oil cooling system. Barrel is cooled by special wind cooling system.
Specifications:
|
Model |
SJSZ65/132,SJSZ80/156,SJSZ92/188 |
|
usage |
extrusion outdoor decorative |
|
raw material |
recycled PE/PP,wood powder, additive material,etc |
|
product size |
maximum:400mm,or according to prdroduct’s drawing |
|
Extruder feature |
Special designed extruder |
|
wood powder ( wood fiber) |
high volume of addition up to 50~75 percent |
|
Plastic proceed |
PP,PE,PVC,wood plastic composite |
|
Auxiliary machine |
Emboss machine,sanding machine,polishing machine |
|
Product type |
Dustbin, Sound insulation board |
Competitive Advantage:
1 . good after-service
2 . spare parts are free
5 . have many years experience
