Plastic Sheet Extrusion Line
Created with Pixso.

PE / PP / HDPE / PET Plastic Sheet Production Line For Decorative

PE / PP / HDPE / PET Plastic Sheet Production Line For Decorative

Brand Name: AORUI
Model Number: SJ90/33
MOQ: One set
Price: Negotiable
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Detail Information
Place of Origin:
China
Certification:
CE UL CSA
Automatic:
Fully Automatic
Voltage:
380V 50HZ
Place Of Original:
Shandong , China
Port:
QingDao
After-sales Service:
Engineers Availiable To Service
Screw Design:
Single Screw
Application:
Sheet
Packaging Details:
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Supply Ability:
10 Sets per month
Highlight:

plastic sheet production line

,

plastic sheet extruder machine

Product Description

Plastic Sheet For PE / PP / HDPE / PET , Plastic Sheet Extrusion Line For Decorative





QUICK DETAIL :



1. PE/PP foamed board product has such features as heat-proof high strength, good heat separation, fine elasticity, good rot resistance, non-toxic, recycle, etc.



2. Applications: Such as packing, heat separation material and carriage, etc.



Description:





    1. The plastic sheet production line has such features as healthy, flame retardant, isolation, waterproof, wetproof, shock reduce,      buffering, temperature keeping, heat separating, aging resistance, rot resistance, light, easy to thermoform, etc.



    2. About all parts of the equipment is adopted known brand products.Our company had experiences and technologies made plastic plates(sheets),so it has the easy operation,and the products made by us has characteristics of low cost. Clean outside,little error,antiseptic,insulation and othere merits.



   3.Best Price PE PVC WPC PP Wood Plastic Sheet Board Extrusion Machine Production Line Manufacturer. This qualified extrusion line is main for producting PE pressure pipes,discharge pipe line for chemical and food fields,protection and conduit pipes for electrie cables and communication wire,fishpond edge guardrail pipes etc.





      Applications:



This line is specially used for producing PP/PE single layer or multi-layer sheet or plate, suitable in the fields of packaging, stationery, chemicals, construction, household appliances and so on.




Specifications:





Extruder Model LMSB-90/33 LMSB-100/33 LMSB-120/33 LMS-100/65 LMSB-120/65
Sheet Width 300-610mm 500-950mm 1000-1500mm 500-950mm 1000-1500mm
Sheet Thickness 0.15-1.4mm 0.15-1.4mm 0.15-2mm 0.25-1.4mm 0.25-1.4mm
Driving Motor 75KW 90KW 132KW 90KW,75KW 132KW, 65KW
Line Speed 25m/min 25m/min 28m/min 28m/min 28m/min
Capacity 180kg/h 300kg/h 550kg/h 450kg/h 650kg/h





Competitive Advantage:



1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
