Product Details:
|
| Certification: | CE & ISO9001 | Condition: | New |
|---|---|---|---|
| Screw Design: | Twin Screw | Autoamtic Grade: | Fully Autoamtic |
| Brand Name: | AORUI | After-sales Service: | Engineers Availiable To Service |
| Place Of Origin: | Shandong , China | Plastic Processed: | PVC |
| High Light: | Plastic Profile Production Line,Plastic Profile Extruder |
||
Wood Plastic Profile Production Line , PVC Profile Extrusion Machine / Profile Extruder
Quick detail:
1. Wood-plastic profile extrusion line adopt special design screw & barrel, die head and processing technique for wood plastic products.
2. Products including: One step wood-plastic thick plate equipment; one step wood-plastic profile equipment, one step wood-plastic decorative material equipment, wood-plastic granulation equipment, all sorts of wood-plastic die head.
3. The profile extrusion machine can produce PE , PP or PVC and wood profile products. These products are mainly applied for making pallets , packing cases, floors , wall decoration materials and other wde applications.
Description:
1. The pvc profile extrusion machine has such characteristics:New energy saving technology . High output capacity . High accuracy. Long using life.
2. The main components of PVC profile machine including:
Powder feeder. Twin-screw extruder. Vacuum calibration table. Haul-off unit. Cutting unit. Profile stacker
3. The output capacity of main extruder is from 150kg/h to 450kg/h for option. Haul-off machine is specially designed with particular up and down technology of our company, working stable, reliable and heavy duty force. Vacuum sizing tank having particular dig eddy low cooling system for cooling and sizing easy for high speed extruding necessary. The action of cross direction saw cutter keeping synchronous with haul-off controlled by import PLC controller, reasonable design, running stable.
4. Series PVC profile extrusion line is mainly used in PVC door & window profiled material,wide door plate, window plate, extrusion of multi-holes pipe for passing through lines(four holes, six holes, seven holes, nine holes, etc.) For different sectional surface and molds, twin parallel(conical) screws extruder of different specifications can be chosen together with corresponding vacuum calibrating table, haul-off unit, cutting unit, tilter, etc.
Applications:
The pvc profile extrusion machine can produce PE , PP or PVC and wood profile products. These products are mainly applied for making pallets ,packing cases , floors , wall decoration materials and other wide applications. The wood powder or plant fiber can be put up to max , 50-70%. This machine can produce the PP , PE , PVC , ABS ,PS and etc.
Specifications:
| item | SJSZ51/105 | SJSZ65/132 | SJSZ80/156 | SJSZ92/188 |
| Screw Diameters(mm) | 51mm/105mm | 65mm/132mm | 80mm/156mm | 92mm/188mm |
| Output(kg/h) | 80-120 | 160-200 | 250-350 | 400-500 |
| Main driving power(kw) | 18.5 | 37 | 55 | 90 |
| Heating Power(kw) | 3 Zones,18kw | 4 Zones,20kw | 5 Zones,38kw | 6 Zones,54kw |
Competitive Advantage:
1. CE & ISO9001 certificate
2. we have good quality and reasonable price
3. easy operate and maintain
4. technical assistance
