PET Strapping Band Machine , PET / PP Strapping Band Production Line / Strap band Extruder

PET Strapping Band Machine , PET / PP Strapping Band Production Line / Strap band Extruder


Quick detail:

OVERVIEW OF PET STRAPPING ROLL MAKING MACHIN

1. Processing material: 100% recycled PET flakes or virgin PET (I.V ≥0.75)
2. Strap width: 9-32mm
3. Strap thickness: 0.5-1.2mm
4. Quantity of extruded straps band: 4strands/ 2 strands/1 strands
5. Max output: 80 - 400kg/hr
6. Max Liner speed: 120m/min
7. Power supply: 380V/3P/50Hz
8. Installed power: 410KW (production power: about 200KW)
9. Operators: 2-4
10. Overall dimension: 45m × 3m × 4.5m

Description:


1. The "non-sandwich" strap possesses the quality of relitively light weight,low skewness,stable production quality,bright color,high lustrousness,high tension strength,suiting for different kind of packer to pack.The straps produced by the machine can be equaled.With the straps produced in Japan and Korea.Far ultra red heater,four-time heated,computer-controlled laser embossing roller can emboss delicate tracery.Unique tape equitement ensures the head face orderly and even.After being wrapped up,the straps is deformed little,guaranteed users automatically packing smoothly conduct.

2. Single screw or twin screw technique for option depending on the requirement. 100% recycled flakes can be used for production. Even plasticzation and stable extrusion with PC automatic control for the full line, the dosing pump ensures continuous and stable production. The filter of double columns with four working positions can get rid of impurity effectively. Single strap or double strap for option.


Technological parameter:



Application :

Application: PET straps for cotton bales, for Can Package, for Paper Industry, for strapping Steel Coils, for Clay Building Bricks, for Aluminum Ingots, for Fibre Bales, etc.

Competitive Advantage:

1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
