Product Details:
|
| Brand Name: | AORUI | Condition: | New |
|---|---|---|---|
| Screw Design: | Double Screw | Certificate: | CE & ISO9001 |
| Automatic Grade: | Fully Automatic | Weight: | 8T |
| After-sales Service: | Engineers Availiable To Service | Application: | Profile |
| High Light: | Plastic Profile Production Line,Plastic Profile Extruder |
||
PVC Profile Production Line , pvc Door And Windows Making Machine , Plastic Profile Extruder
Quick detail:
1. PVC doors and windows making machine can produce all kinds of profile, for example, window, door and door frame, pallet, cladding of outdoor wall, faciliry of ourside park, floor etc. Output profile is Wood Plastic Composite(WPC) or Plastic UPVC.
2. The pvc profile machine uses the special designed screw and barrel , die and extrusion process to produce plastic and wood profile extrusion machine.
3. Materials: PVC/PP/PE + Wood Powder or PVC, PE, PP.
Description:
1. This series production line is designed for extrusion of PVC plastic fence’s profile and crosssection
cable pipes,aluminum-plastic composite profiles and etc.PVC profiles are widely used in the building industry,home and office decoration.
2. To produce PVC profile, you shall have high speed mixer to mix PVC powder, CACO3 and other additives according to your formula. Then feed the mixture to the conical twin screw extruder for the production. The mixed material will be extruded through different molds to produce different shape profiles. Then it will be calibrated to keep the shape by vacuum calibration tank, then haul off and cutting. You could cut different length as you want, 4 meter, 6 meter, etc.
Applications:
The pvc profile production line is suitable to produce the PP, PE, PVC + wood composite products, the WPC products are strong and durable, both have the advantages of plastic and wood products, at the same time, they overcomes the shortages of plastic products that is easily got deformed, and the wood products can easily get corrosion, damaged by worms, short service life, etc. They are popularly used as packing case and wood-polymer tray; flooring panel, indoor and outdoor decoration, plank flooring, pavilion and chair in park, etc. The amount of wood power or fibers can reach to 50-70%.
Specifications:
| Model | SJZ51/105 | SJZ55/100 | SJZ65/132 | SJZ80/156 | SJZ92/188 |
| Screw diameter(mm) | 51/105 | 55/100 | 65/132 | 80/156 | 92/188 |
| Quantity of screw | 2 | 2 | 2 | 2 | 2 |
| Max. rotation speed of screw(r/min) | 40 | 38 | 38 | 37 | 36 |
| Effective length of screw(mm) | 1200 | 1200 | 1440 | 1800 | 2500 |
| Main motor power(kw) | 18.5 | 22 | 37 | 55 | 110 |
| Productuion capacity(kg/h) | 100 | 150 | 250 | 400 | 750 |
| Center height(mm) | 1000 | 1000 | 1000 | 1100 | 1200 |
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
