Product Details:
|
| Temperature Control: | Omron | Motor: | Simens |
|---|---|---|---|
| Nitrided Layer Thickness: | 0.4-0.7mm | Screw Number: | Two |
| Condition: | New | Place Of Original: | Shandong , China |
| Port: | Qingdao | Delivery Time: | About 35days |
| High Light: | wpc profile extrusion line,wood plastic machine |
||
New Technology Wood Plastic WPC Profile Production Line , Wood Foamed Profile Extrusion Machine
Quick detail:
1. Wood Plastic Door Panel Extrusion Line collects the advantages of wood and plastic. It not only has appearance of natural wood, but also overcomes shortcoming of wood, it has good processing performance which is similar to wood, it can be sawed and nailed. It can be finished with wood working tools. Its fixed force is clearly stronger than normal wood material.
2. Flow Process:
1.PE/PP+wood extrusion line craft:
Wood milling(wood powder,rice husk)-- Mixer(plastic+wood)--Granulator--Wpc extrusion line+Auxiliary
2.PVC+wood extrusion line craft:
Wood milling(wood powder,rice husk)--Mixer(plastic+wood)--Wpc extrusion line+Auxiliary
Description:
1. Suitable to produce UPVC/PVC/WPC series profile, such as PVC cable trunking, PVC ceiling, pvc decking, flooring, pvc window profile and door frame and board widely. Conical twin-screw extruder is perfect, with PVC powder or granular material. Mould designed by different kinds of profile customer required. supply formula guide and staple raw material purchase.
2. It's continuously improved on the basis of requirements and feedbacks from our customers and combined with foreign advanced technology. It shows superior performance, high reliability and practicality with its compact structure, advanced configuration and outstanding output in the production of 3-20mm thick, high-qualified and colored PVC and WPC foam board.
3. The machine can produce PE PP or PVC and wood profile products.These products are mainly applied for making pallets , packing cases , floors , wall decoration materials and other wide applications. The wood powder or plant fiber can be put up to max , 50-75%. This machine can produce the PP , PE , PVC , ABS , PS and etc.
Applications:
Features and application :
It has referred to the latest foreign technology and has optimized the design.
It has such advantages as even plastication, small shearing speed, high output, long life span, etc.
The main motor has applied imported inverter, temperature control apparatus are products of RKC of Japan.
Auxiliary vacuum pump and drawing motor are all excellent quality products.
It is simple to maintain.
It may also directly extrude wood like balpo different shaped material, the effect is better than that of single screw extruder.
If plasticated steel door & window different shaped material production line is used together with cone double screw extruder,
it may process PVC plastic door & window different shaped material, steel-plastic compound different shaped material, different shaped multi-hole tubes for cables, shaped material for decoration, etc.
Specifications:
| Items | YF180 | YF240 | YF300 | YF600 | YF900 | YF1200 |
| Max.width of board(mm) | 180 | 240 | 300 | 600 | 900 | 1200 |
| Drawing height(mm) | 150 | 150 | 150 | 150 | 150 | 150 |
| Drawing speed(KN) | 2 | 2 | 2 | 30 | 40 | 50 |
| Drawing speed(m/s) | 0-5 | 0-5 | 0-5 | 0-3 | 0-2.5 | 0-2.5 |
| Auxiliary equipment sum power(kw) | 35 | 35 | 30 | 30 | 40 | 45 |
| Cooling water consume | 6 | 6 | 6 | 9 | 12 | 15 |
| Compression air(Mpa) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
