| Brand Name: | AORUI |
| Model Number: | SJ-65/33 |
| MOQ: | One set |
| Price: | Negotiable |
| Payment Terms: | T/T L/C |
| Supply Ability: | 10 Sets per month |
Super Quality PET Granules Production Line , PET Flakes Recycled Plastic Granulator Machine
QUICK DEATIL :
1. PET granule production line Manufacturing Process:
Use a Spiral charger to feed materials into the Extruder materials evenly squeezed, melted and plastified in the Extruder material strips coming out from the machine head, after Degassing and filtering system (Hydraulic Screen Changer) material straps being cooled by Water tank being dried by Strong air dryer being transferred and cut in the Pelletizer being collected by Silo the End.
2. This production line is composed of special designed agglomerator, single-screw extruder, screen changer, dryer, vibrator and packing system, etc.
1. Greatly increase output
2. Continuous production
3. Flexible pelletizing style
Description:
1. Special for waste plastic recycling, and convert to PP PE PET PS ABS PA PVC etc granules. Special for plastic compound filling masterbatch .such as pp / pe+caco3. Two stage machine has better performance in recycling pvc and filling masterbatch !
2. The machine is used to make salvage Polypropylene, polystyrene materials into pellets. The machine can press and pull the material into to strip with the high temperature ,the plastic strip can be cut into pellet by the cuttingmachine. It is equipped with quick motor-operated filterscreen replacing unit and automatic temperature control. The granulating crusher uses adjustable speed motor,pelleting with an extruding machine at the same discharging.
3. The extrusion machine using material of PP, PE as raw materials which should been heated, extruded, cooled, cut & drawn to the flat fibers. The flat fibers would be rolled on the bobbins for weaving the sacks by the circular loom. The flat fibers can be drawn by the materials is including of the reclaimed materials, powder or pellet materials and the mixed materials of them. In this case, the suitable range of the materials has been extended more. Then machine unit can save the power consumptions. It's quite convenience for operating & maintenance of the machine unit.
Applications:
PET granule production line Manufacturing Process:
Use a Spiral charger to feed materials into the Extruder materials evenly squeezed, melted and plastified in the Extruder material strips coming out from the machine head, after Degassing and filtering system (Hydraulic Screen Changer) material straps being cooled by Water tank being dried by Strong air dryer being transferred and cut in the Pelletizer being collected by Silo the End.
Specifications:
| Total capacity(L) |
Effective capacity (L)
|
Mixer speed (rpm)
|
Motor power (KW)
|
Heating Method
|
Discharge Method
|
Dimensions (mm)
|
Weight(t)
|
|
200/500
|
150/
320
|
475/950/130
|
30/42/
11/9
|
Electric/self-friction
|
Manual/ Pneumatic |
4850/
2240/2470 |
3.5
|
|
300/600
|
200/
360
|
475/950/130
|
40/55/
11/9
|
Electric/self-friction
|
Manual/ Pneumatic |
4680/
2240/2740 |
3.8
|
|
300/1000
|
200/
640
|
475/950/110
|
40/55/
15/9
|
Electric/self-friction
|
Manual/ Pneumatic |
4980/
2500/2740 |
4.2
|
|
500/1000
|
375/
640
|
430/860/50
|
47/67/
15/12
|
Electric/self-friction
|
Manual/ Pneumatic |
5580/
2700/3432 |
5.8
|
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
