Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant

Certification
China QINGDAO AORUI PLASTIC MACHINERY CO.,LTD1 certification
Customer Reviews
The sales have good service, it brings me a good experience. We import 5 sets extruders from this company, the extruders have good quality and long service life. I'd like to cooperate with this company for long time.

—— Andrew

The pvc board extrusion machine is good quality , it is beautiful and the output is stable , this is a reliable company

—— Albert

This machine is very good , and the after-saes service is good. The pvc board machine is easy to operate and the output is stable

—— Nancy

I'm Online Chat Now

Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant

Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant
Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant

Large Image :  Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant

Product Details:
Place of Origin: China
Brand Name: AORUI
Certification: CE UL CSA ISO9001
Model Number: SJ-90/33
Payment & Shipping Terms:
Minimum Order Quantity: One set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month

Single Screw Plastic Granules Machine For Granulating , PET Bottle Recycling Plant

Description
Condition: New Screw Design: Single Screw
Brand Name: AORUI Certificate: CE & ISO9001
Application: Granules Machine Place Of Original: Shandong , China
Warranty: 12 Months
High Light:

Plastic Pelletizing Machine

,

Plastic Granulating Machine

Plastic Granules Machine For Granulating , PET Bottle Recycling Plant







QUICK DEATIL :



PET flakes granulate machine

Technical Parameter :

1.Screw diameter(mm):91

2.Inner diameter of bottle(mm):92

3.Screw speed(r/min) :400

4.Driving motor power(Kw):135

5.Center distance(mm):78

6.Screw groove depth(mm): 14

7.(L/D):36 :1

8.Lubricating method:force lubrication





Description:



1. This production line is composed of special designed agglomerator, single-screw extruder, screen changer, dryer, vibrator and packing system, etc.

Greatly increase output
Continuous production
Flexible pelletizing style



2. Special for waste plastic recycling, and convert to PP PE PET PS ABS PA PVC etc granules.
Special for plastic compound filling masterbatch .such as pp / pe+caco3.
Two stage machine has better performance in recycling pvc and filling masterbatch !


3. Screw diameter : 71mm. L/D= 36:1/40:1/44:1/48:1. Main drive motor :AC 132kw,speed regulated by ABB transducer inported from switzerlad. Screw rotary speed:50~600rpm. Screw shaft is made of high-strength alloy 40CrNiMoA. Lenght of each barrel is 290mm,totally 9 pieces of barrels. The 1st barrel is the main feeding vent,the 5th is for degassing,8th is vacuum section,and the others are closed barrels. Casting copper heaters for 2.3th barrels.The others are equipped with casting aluminum heaters,All heating power:~50 kw.







Applications:



PET granule production line Manufacturing Process:
Use a Spiral charger to feed materials into the Extruder materials evenly squeezed, melted and plastified in the Extruder material strips coming out from the machine head, after Degassing and filtering system (Hydraulic Screen Changer) material straps being cooled by Water tank being dried by Strong air dryer being transferred and cut in the Pelletizer being collected by Silo the End.





Specifications:





Total capacity(L)
Effective capacity (L)
Mixer speed (rpm)
Motor power (KW)
Heating Method
Discharge Method
Dimensions (mm)
Weight(t)
200/500
150/
320
475/950/130
30/42/
11/9
Electric/self-friction

Manual/

Pneumatic

4850/
2240/2470
3.5
300/600
200/
360
475/950/130
40/55/
11/9
Electric/self-friction

Manual/

Pneumatic

4680/
2240/2740
3.8
300/1000
200/
640
475/950/110
40/55/
15/9
Electric/self-friction

Manual/

Pneumatic

4980/
2500/2740
4.2
500/1000
375/
640
430/860/50
47/67/
15/12
Electric/self-friction

Manual/

Pneumatic

5580/
2700/3432
5.8





Competitive Advantage:



1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
