Product Details:
|
| Brand Name: | AORUI | Condition: | New |
|---|---|---|---|
| Screw Design: | Double Screw | Automatic Grade: | Fully Automatic |
| Machine Color: | Bule Or According To Customer's Requirement | Processing: | Extrusion |
| Place Of Original: | Shandong, China | ||
| High Light: | plastic sheet production line,plastic sheet extruder machine |
||
Plastic Sheet Extruder Machine , Plastic PVC Sheet Production Line
QUICK DEATIL :
1. The pvc sheet has such characteristics as high impact resistance, high rot resistance, high rot resistance, high temperature resistance , non-toxic , smooth surface , light , easy to thermoform,etc.
2. Taking advantages of its practical, affordable and simple features, this wood texture vinyl flooring is widely applied to home, office, school, supermarket and hospital as the ideal decoration material. As a high quality vinyl plank, it has stood the test of time and market.
3. Product Advantages:
Selecting the superior quality of raw material.
A wide range of applications.
Simple and practical design, easy to install.
Offering an affordable price but excellent quality.
Various choices of color and size.
High performance water proof, anti-slip, fire resistance and wear resistance.
Description:
1. PVC Sheet extrusion Line has such characteristics as high intensity, good temperature resistance, good rot proof, etc. PVC sheet extrusion line can be produced with additives to different requirement such as improving intensity, improving toughness, improving rigidity, flame retardant, embossing, frosting, etc.
2. Applications: Such as packing, printing, stationery, art works, etc.
Main product: Gift/ad/file bag, lamp cover, food packing, etc.
Production scope: Thickness 0.2-2mm width 700-2100mm.
This sheet extrusion line contains: Extruder, Screen exchanger, Mould, Three-roller calender, Temperature controller, Cooling carrier frame, Haul-off, Cutter/Winder. Optional device: Hydraulic measuring pump, laminator.
3. Features of Machine
1. Screw apply special design of mixing and plasticization funtion;
2. Coat hanger type die withtwo throttle design enalble to regulate the sheet thickness accurately;
3.Sheet thicknes shall be regulated by screw and pressing roller;
4. Separete roller temperature control system can make even sheet thickness
5. Winder withbig torque motor, regulate its speed and tension force;
6. Automatic metering device can pre-set the length of product.
Applications:
Main Technical Parameters:
Project / Mod
| el Model | Extruder | Width of product (mm) | Linear velocity (m/min) | Max output(kg/h) |
| Three-roller calender | ||||
LPF1500 |
SJZ80 | 700-1500 | 1.5-15 | 300 |
LPF2100 |
SJZ92 | 700-2100 | 1.2-12 | 600 |
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
