PVC Plastic Sheet Extrusion Line , Low Price PVC Decorative Sheet Making Machine
Quick Detail:
1. PVC WPC Artificial Marble Decoration Sheet Board Panel Production Extrusion Extruder Extruding Manufacturing Making Machine
This sheet board panel production extrusion extruder extruding manufacturing making machine produce the sheets widely used in hot spring resorts, bath club, KTV, office building, hotel, subway and other high-level places. It's the ideal decoration material in the moist environment.
2. Processing flow:
500/1000Mixer→Auto loader→SJSZ80/156 conical twin screw extruder →Mould→
Three calender(online laminating) →Cooling group rollers→Hual off machine→ Transversal cutter
→Edge cutter→ Conveyor→UV treatment.
Description:
1.The main machine adopts imported AC frequency converter driving. The temperature control meters adopt Japan RKC product. The ancillary machine vacuum pump and drawing motor adopt high-quality products. The maintenance is simple. After the screw stem cylinder and mould are exchanged, it can straight extrude imitating wood foamed special material. The result is better than the single screw stem extruder. The sheet extruding production line adopts special-designed screw stem, material cylinder, moulds and processing technology. It is equipped with YF model shaped material ancillary to produce PVC products.
2. Component of the completed production line:
1) SJSZ-65/132 conical twin screw extruder
2) Forming mould
3) SDT-6000 vacuum calibrating table
4) SLQ-200 haul off unit
5) Cutting unit
6) Stacker
3. 1) The main motor, machine and tractor operators using variable frequency control system, easy to adjust, reliable to run, stable, low energy consumption.
2) The screw of extruder with special design, better effective plasticization of raw materials, stable production.
3) High efficient, easy in installation and maintain.
4) Adopting advanced world famous brand components in pneumatic parts,electric parts and operation parts.
5) Running in of high automatization and intellectualization, no pollution.
6) Support with professional technical persons and one year warranty.
Applications:
Main Technical Parameters:
Project / Mod
| Model | LMSB65/132 | LMSB80/156 | LMSB92/188 |
| Max product width | 1000mm | 1500mm | 2000mm |
| Products thickness | 0.5-3mm | 0.5-3mm | 0.5-3mm |
| Extruder model | SJ-65/132 | SJ80/156 | SJ-92/188 |
| Main motor power | 37kw | 55kw,75kw | 75kw, 110kw |
| Capacity | 250kg/h | 360kg/h | 550kg/h |
| Total line Length | 22m | 28m | 35m |
Competitive Advantage:
Equipment warranty
1. About the equipment, Middle tech promised the good quality of 12 month.
2. during the warranty, no purposely and artificially damage change the damaged part, we will free
maintenance and technical services.
3. Over 12 months, Buyer's needs to pay the producing cost of the worn part, and life-long supply the part of equipment and freely device
