Product Details:
|
| Brand Name: | Aorui | Payment Terms: | TT Or L/C |
|---|---|---|---|
| Condition: | New | Motor: | Siemens |
| Temperature Controller: | Omron | Plastic Processed: | PE PP |
| High Light: | plastic pipe extruder machine,plastic pipe production line |
||
Double Wall Corrugated Pipe Extrusion Machine , PE Plastic Pipe Production Line
Quick detail:
1. The production line is designed for making Krah pipe. This kind of pipe is made from HDPE or PP, which has been widely used for drainage and water supply applications.
2. We use the most advantage technics to design the production line. Our engineer has years experience in the making of the production line, also trained in Germany.
Description:
1. Introduction of PE/PP Spiral Corrugated Pipe:
1) Light weight-per-meter
2) Belling link, tight cementation
3) Pressure against, high strength
4) Anti-frozen and long service life(50 years )
5) Convenient construction
2. Introduction of PE/PP Spiral Corrugated Pipe Extrusion Machine:
HDPE spiral corrugated Pipe production line is a kind of new generation high performance plastic spiral pipe line for large diameter buried drain pipe according to Corrugate pipe production technology. It can produce pipe size from Ø 200~Ø 2000mm which is widely used in fields of civil water drain, wastewater drain. The pipe could also be made by the recycled polyethylene material. These properties make it superior advantages compared with other kinds of drainpipe.
Applications:
1, Light weight: the spiral structure makes the duct lightweight and easy to transport and install.
2, High strength: because of the spiral structure, the ring stiff is high and the pipe can bear the load effectively with no deformation
3, Terrain adaptability: tension and break resistance and adapt the terrain change well.
4, Corrosion resistance: acid & corrosion, no electrochemical corrosion, long service life.
5, Electric insulation: it is totally immune to galvanic or electrolytic attacks.
6, Easy to install: join the duct by its helix without other tools
7, Good heat dissipation: cables is floating in the duct and the heat dissipates more evenly
8, Efficient drawing of cables: The spiral structure reduces the surface contact between the cable and duct. The low traction resistance improves the efficiency of drawing of cables
Specifications:
| Model | SJ-90/30 | SJ75/30 | SJ-65/30 | SJ-45/30 |
| Screw diameter(mm) | ø90 | Ø75 | ø65 | ø45 |
| L/D | 30:1 | 30:1 | 30:1 | 30:1 |
| Output(kg/h) | 200 | 150 | 100 | 40 |
| Total power(kw) | 120 | 100 | 80 | 50 |
| Pipe range(mm) | ø110-ø200 | Ø65-ø110 | ø16-ø75 | ø8-ø50 |
| Haul off speed(m/min) | 10 | 10 | 10 | 15 |
| Capacity annually(1okm) | 150 | 150 | 150 | 150 |
Technical and after-sales service:
The supplier the following technical and after-sales service commitment
A) Provide on-site installation guide;
B) Responsible for the commissioning of equipment;
C) Responsible for the buyer's personnel mount guard before the operation and maintenance training;
D) One year free warranty (due to the buyer's improper operation caused by damage charge costs), and ensure the supply of spare parts for a long time, only receive the cost.
E) Provide technical advisory services for a long time
