PET Bottle Plastic Granules Machine , PET Bottle Recycling Pellet Extrusion Machine

Brand Name:	AORUI
Model Number:	SJ65/33
MOQ:	One set
Price:	Negotiable
Payment Terms:	T/T L/C
Supply Ability:	10 Sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE UL CSA

After-sales Service:

Engineers Availiable To Service

Warranty:

1 Year

Automatic Grade:

Fully Automatic

Voltage:

380V 50HZ

Screw Design:

Single Screw

Place Of Original:

Shandong , China

Packaging Details:

Fumigation wood, film,pallet,etc or according to customer’s requirement.

Supply Ability:

10 Sets per month

Highlight:

Plastic Pelletizing Machine

Plastic Granulating Machine

Product Description

PET Bottle Plastic Granules Making Machine , PET Bottle Recycling Pellet Extrusion Machine

QUICK DETAIL:

1. PET bottle granules making machine:

1.Raw material: PET bottle/flakes

2.Final product: PET granules

3.Hydraulic screen changer

4.Special vacuum degassing system

5.Output:100-800kg/h(according to customer requirements)

6.Cutting type of PET bottle granules making machine : water cooling strand

2. Flow chat PET bottle granules making machine:

Water strand pelletizing

Parallel twin screw extruder→ hydraulic screen exchanger →Die head→Water cooling tank → Air blower dryer→Granulator

Description:

1. Brief introduction: Water ring cover is aluminum casting, precision machining of internal flow channel and thickness of water, the distance of cooling material is long, can effectively avoid secondary adhesion. It is particular suitable for low viscosity of thermoplastic elastomer extrusion and granulating.

2. Application for water-ring pelletizing:

1. Master batch and color master batch:

PP/PE/ABS+Caco3/Sio2(silicon dioxide)/talc(chalk)/carbon black

2.Thermoplastic elastomer:

PP+SBS=TPR, PP+SEBS=TPE, PP+EPDM=TPV

3.Cable material:

LDPE/HDPE/LLDPE/crosslinked cable material

Applications:

1. Many materials can be processed directly without need of the upstream pre-shredding,resulting in a dramatic

reduction in operational costs.
2. Less power consumption cost per kilogram,high throughput,reduced floor space occupation and

operator attendance.
3. Applicable plastic materials: PP, HDPE, LDPE,LLDPE,TPV,EVA,ABS and PS,etc

Material shapes: film,bag, flake

Specifications:

Model	SHJ-50	SHJ65	SHJ-72	SHJ-92
Screw diameter (mm)	50.5	62.4	71.2	91
Rotary speed (rpm)	500/600	400-500	400/500	400/500
Main motor (kw)	37/45	55/75	90/110	220/250
L/D	32-38	32-48	32-48	32-40
Capacity (kg/h)	80-150	150-300	300-600	600-1000

Competitive Advantage:

1. To install products and test products freely for customers.
2. To direct technology aspect of relevant use according to customers’ requirements
3. To provide technical training for clients’ employees.

PET Bottle Plastic Granules Machine , PET Bottle Recycling Pellet Extrusion Machine 0
