Wood Plastic Profile Extrusion Line For PVC Cable Trunking Profile Extrusion

Brand Name:	AORUI
Model Number:	SJ90/33
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T L/C
Supply Ability:	10 sets per quarter

Detail Information

Product Description

Detail Information

Place of Origin:

ShanDong China

Certification:

CE UL CSA ISO9001

Voltage:

380V 50HZ

Brand Name:

Aorui

Condition:

New

Automatic Grade:

Fully Automatic

Place Of Original:

Shandong , China

After-sales Service:

Engineers Availiable To Service

Packaging Details:

Fumigation wood, film,pallet,etc or according to customer’s requirement.

Supply Ability:

10 sets per quarter

Highlight:

Plastic Profile Extrusion Machine

Plastic Profile Extruder

Product Description

Wood Plastic Profile PVC PP PE Profile Production Line , PVC Cable Truncking Profile Extrusion Machine

Quick detail:

1. Material can be extruded out directly after two grades of mixing, and it can also be extruded by two steps after pelleting. The line is of characteristics of energy and space saving, high output, stable performance etc.

2. Preheating feeder is installed at the top of extruder, which will dry the wood powder firstly, thus perfect plasticization is guaranteed. Special-designed screw will minimize cutting force, which provents wooden fiber from being damaged. Both screw and barrel are speacial-treated, which are featured of abrasion proof and long life-span.

Description:

1. This AORUI series of plastic extrusion plate type hydraulic screen changer consists of main body, sliding plate, heater unit and hydraulic unit with accumlator. It's ariven by hydraulic system, and the sliding plate carrying 2pieces of breaker lates move linearly in both directions to achievescreen changing process smoothly.

2. The machine can produce PE,PP or PVC and wood profile products. These products are mainly applied for making pallets , packing cases , floors , wall decoration materials and other wide applications. The wood powder or plant can be put up to max , 50-75%. This machine can produce the PP , PE, PVC,ABS , PS and etc.

Technical Parameters:

Items	YF180	YF240	YF300	YF600	YF900
Max.width of board(mm)	180	240	300	600	900
Extruder Model	SJZ55/110	SJZ65/132		SJZ80/156	SJZ92/188
Mian motor power(KW)	22	37		55	110
Drawing height(mm)	150	150	150	150	150
Drawing speed(KN)	20	20	20	30	40
Drawing speed(m/s)	0-5	0-5	0-5	0-3	0-2.5
Auxiliary equipment sum power(kw)	35	35	30	30	40
Cooling water consume(m 3 /h)	6	6	6	9	12
Compression air(Mpa)	0.6	0.6	0.6	0.6	0.6

Competitive Advantage:

24 hours services;
Overseas installation;
Free operation training and technology formula transfer;
Old machine update;
Spare parts and maintenance with reasonable cost price.

Wood Plastic Profile Extrusion Line For PVC Cable Trunking Profile Extrusion 0
