Product Details:
|
| Model Number: | SJSZ65/132 | Condition: | New |
|---|---|---|---|
| Delivery Time: | 35 Days | Place Of Original: | Shandong , China |
| Forming Way: | Extrusion | Voltage: | 380V 50HZ |
| High Light: | Plastic Profile Extrusion Machine,Plastic Profile Extruder |
||
50HZ WPC Profile Extrusion Machine , Door And Window Frame Plastic Profile Extruder
Quick detail:
1. AORUI series conical twin screw extruder is a highly efficient agglomeration and extruding equipment. Machines of this series feature low shearing rate, uneasy degradation,even plastication and agglomeration, reliable quality,wide application range and long servicing life.
2. Using PE powder as raw material for a direct forming, the exturders perform an excellent effectiveness. These machines have automatic temperature control, vacuum gas exhaustion, oil cooled screws, stepless speed regulation, as well as a forced and self-cleaning mechanism.
Description:
1. AORUI series wood plastic composite wpc profile machine production line mainly use pvc/pe recycle+wood powder, producing skirting, window and door frames, furniture edge, door pocket, decorative profiles, etc. The wpc line use our original wood plastic technique and formula, design the proportion of different wpc products according to their different profile section, usage, etc.
2. Equipment list for the wood plastic wpc profile machine
Technical Parameters:
| Extruder model | SJZ55/110M | SJZ65/132M | SJZ80/156M | SJZ92/188M |
| Main motor power(kw) | 22 | 37 | 55 | 110 |
| Down-stream equipment model | YF240S | YF240A YF300A |
YF600 | YF900 YF1200 |
| Product width(mm) | Max240 | Max240 Max300 |
Max600 | Max900 Max1200 |
| Vacuum pump(kw) | 2*5.5 | 4*5.5 | 1*7.5 2*11 |
1*7.5 2*11 |
| Water pump(kw) | 1.5 | 4 | 7.5 | 7.5 |
| Haul-off speed | 0-5 | 0-5 | 0-3 | 0-2.5 |
| Down-stream equipment power | 22 | 35 | 44 | 52 62 |
| Output(kg/h) | 70 | 120 | 180 | 400 |
Competitive Advantage:
experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology
Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.
After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
