Product Details:
|
| Condition: | New | Application: | Pipe |
|---|---|---|---|
| Place Of Original: | Shandong , China | Automatic Grade: | Fully Automatic |
| Screw Design: | Double Screw | Certificate: | CE ISO9001 |
| After-sales Service: | Engineers Availiable To Service | ||
| High Light: | plastic extruder machine,plastic production line |
||
PVC Plastic Pipe Extrusion Line , PVC Fiber Reinforced Soft Pipe Extrusion Machine , PVC Pipe Extruder
Quick Details:
1. Braided Fibre Reinforced Hose is also called PVC Fiber Enhancing Soft Pipe, whose wall has three layers, outer and inner layer are soft PVC hose, middle layer is ethylene fiber network, which has good chemical and physical property. It is mainly used for the transportation of high pressure or corrosive gas, and is widely used in the machinery; coal mine, oil, chemical, agriculture irrigation, gas and building.
2. Process
conveying feeding→single screw extruder→extruding mould→spray cooling water tank→belt haul-off→
fibre winder→warm up oven→single screw extruder→mould→spray cooling water tank→
belt haul-off →meter measure→winder→finished product inspecting&packing
Description:
1. PVC Braided Fibre Reinforced Hose Extrusion Line is designed to produce PVC fiber reinforced hose and so on. It mainly consists of extruder, spray water tank, traction engine, kinking machine and reeling machine. PVC fibre braided hose production line has a good market in worldwide.We can supply PVC fibre braided hose production.
2. The PVC Fiber Reinforced Flexible Pipe, also referred to grid pipe or snake skin pipe,
is widely used to convey the middle pressure or corrosive gas and liquid.
Now it is widely used in such fields as mechanical engineering, coal min, petroleum, chemical industry,
agriculture irrigation and civil applications (solar water heater or gas-canisters).
At the present time, it is widely used to the irrigation pipe to the garden and lawn
Detail information of spiral wrapping band
Usage |
Use the length you need, fix the one side, and bind the bundled tie by clockwise to make them tighten |
Feature |
The product is easy to disassemble; the winding force will not be weaken when you re-use it. |
Surface color |
grey, white, red, yellow, green etc...other color customized |
Payment Term |
A.L/C,T/T (Bank Transfer, Wire Transfer) |
B. Western Union |
|
C. Paypal (For samples fee & Courier cost) |
|
Price Term |
FOB Shanghai / Ningbo: CIF, CNF, etc |
Supply Ability |
2 x 20 feet containers per week |
Packaging Details |
A. Common Packing:1bag + Blister +Label+ export carton |
B. Common Packing:1bag+inner box + label +export carton |
|
C. Customized Packing: OEM Label, PDQ etc |
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: long available life
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
