Wood Plastic Composite Extrusion Line
Created with Pixso.

Plastic Extruder Wood Plastic Composite Extrusion Line / WPC Decking Making Machine

Plastic Extruder Wood Plastic Composite Extrusion Line / WPC Decking Making Machine

Brand Name: AORUI
Model Number: SJSZ65/132
MOQ: One set
Price: Negotiable
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Detail Information
Place of Origin:
China
Certification:
CE UL CSA
Trademark:
Aorui
Automatic Grade:
Fully Automatic
Application:
Plastic Board
Screw Design:
Double Screw
Voltage:
380V 50HZ
Condition:
New
Packaging Details:
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Supply Ability:
10 Sets per month
Highlight:

WPC Extrusion Line

,

Wood Plastic Production Line

Product Description

Plastic Extruder Machine For Wood Plastic Composite / WPC Decking Making Machine





Quick detail:



1. PVC Wood-Plastic Door Plate Extrusion Line collects the advantages of wood and plastic. It not only has appearance of natural wood, but also overcomes shortcoming of wood, it has good processing performance which is similar to wood, it can be sawed and nailed. It can be finished with wood working tools. Its fixed force is clearly stronger than normal wood material.



2. pplication :
Profiles for the building industry
--windows
--door frame and board
--rolling shutters
--gutters
--fencing
--ceiling
--deck
--floor
Profiles for furnishing
--furniture edge bands
--coatings









Description:



1. The machine is used to produce PVC wood plastic composite products, PVC profile etc;
2. Applied materials: PVC+wood powder, PVC powder material;
3. Features and advantages:

(1) It could produce PE, PP, PVC wood plastic profile, high additive amount of wood powder & plant fiber (max 50-75), strong adaptability, could process PE, PP, ABS, PS etc at the same time;

(2) This is our company's technique-matured machine model, we could supply overall technical support from aspects like raw materials recipe, production technology, mould forming etc.









Specifications:



Model SJZ-45 SJZ-51 SJZ-55 SJZ-65 SJZ-80I SJZ-80II SJZ-92
Screw diameter(mm) 45/90 51/105 55/110 65/132 80/156 80/172 92/188
Max. Rotational speed of screw(rpm) 45 45 45 45 34.7 34.7 34.7
Main motor(kw) 15 18.5 22 30/37 55 81 110
Capacity(kg/h) 110 125 150 260 400 400 800
Central height(mm) 1000 1000 1000 1000 1100 1100 1200
Net weight(kg) 3000 3000 3500 4000 5500 5500 8000
Dimension(L*W*H)(M) 3.3*1.2*2.1 3.6*1.1*2.1 3.6*1.1*2.1 4.2*1.5*2.4 4.7*1.5*2.4 5.0*1.6*2.6 6*1.6*2.5







Competitive Advantage:



experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology

Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.

After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
