PVC Pelletizing Conical Plastic Twin Screw Extruder

Name: PVC Pelletizing Conical Plastic Twin Screw Extruder
Brand: QINGDAO AORUI PLASTIC MACHINERY CO.,LTD1
SKU: SJSZ65x132
Availability: InStock

Brand Name:	AORUI
Model Number:	SJSZ65x132
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T L/C
Supply Ability:	30 sets per quarter

Detail Information

Product Description

Detail Information

Place of Origin:

ShanDong China

Certification:

CE & ISO9001

Condition:

New

Screw Design:

Double Screw

Place Of Original:

China

Application:

Plastic Extrusion

Certificate:

CE Certificate

Warranty Time:

1 Year

Contactor:

Schneider

Temperature Controller Brand:

Omron

Packaging Details:

Fumigation wood, film,pallet,etc or according to customer’s requirement.

Supply Ability:

30 sets per quarter

Highlight:

Conical Plastic Twin Screw Extruder

PVC Pelletizing Twin Screw Extruder

110kg/H Twin Screw Extruder

Product Description

SJSZ65X132 PVC Board Sheet Profile Pipe Conical Twin Screw Extruder With CE Certificate

Quick detail:

Capacity increased (20% higher- vertical gearbox),
Lower noise (around 75db- WEG motor)
Less power consumption (Less 20% consumption- new type of copper heating band)
Longer screw barrel life (Bimetallic barrel coating layer)
Reliable quality (vertical gearbox by SKF bearing)

Description:

1.SJSZ Parallel Twin Screw Extruder adopt building block pricinple design, Accoring to process material system and craft formula requiement the L/D ratio and barrel structure.

2.Screw arranged, screen change way, exhaust number and station, feeding mode, electric control system all can be reasonably optimized and configured.

3.Realize multi - function, multi - purpose to adapt to the processing of polymer materials.

Main Technical Parameter

SPECIFICATIONS FOR Conical Twin-screw Extruder
Extruder model	Max.output (kg/h)	Total power(kw)
GSZ45/100	40-80	15/18.5
GSZ51/105	80-110	18.5/22
GSZ55/110	120-150	22/30
GSZ65/132	280-350	37/45
GSZ80/156	380-450	55/75
GSZ80/173	500-650	75
GSZ92/188	700-850	110/132
GSZ95/196	1000	132/160

Application:

Conical twin screw extruder can be widely used for different PVC plastic products extrusion. Combined use with different plastic auxiliary machines, it can be used for the PVC pipe, PVC profile, PVC board, PVC sheets and PVC pelletizing.special designed conical twin screws designed, which is perfectly good for the PVC extruding.

Our machine competetive advantages:

Stable running

All electric parts are famous brand

Easy to operate

Customer visit our factory:
