Full Automatic Wood Plastic Production Line 3 Phase For Billboard

Full Automatic Wood Plastic Production Line 3 Phase For Billboard

Brand Name: AORUI
Model Number: SJSZ80/156,SJSZ92/188
MOQ: One set
Price: Negotiable
Payment Terms: T/T L/C Western Union
Supply Ability: 10 Sets per month
Detail Information
Place of Origin:
China
Certification:
CE UL CSA ISO9001
Model Number:
SJSZ80/156
Automatic Grade:
Fully Automatic
Raw Material:
PVC
Motor:
Siemens
Temperature Controller:
Omron
Inverter:
ABB
Condition:
New
PVC Board Thickness:
1-40mm
Packaging Details:
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Supply Ability:
10 Sets per month
Highlight:

Wood Plastic Composite Production Line

,

Wood Plastic Production Line

Product Description

Full Automatic Wood Plastic Production Line 3 Phase For Billboard



Description:

WPC CELUKA billboards plastic Machine(1220*2440mm)

1.PVC crust foamed plate plastic extruder adopt the Celuka structural-foam process technology, compared with

the free foamed board, the skinning foamed board has the features of flattening and smooth surface, strong

skinning hardness and stiffness, and better mechanical property.

2.The PVC WPC skinning foamed board extrusion machine is equipped with the conical double screw extruder,

T-type plate mould, vacuum calibrating machine and ten-roller hauling off machine, etc;it will be widely used in

many fields.

3.Application: high-grade cupboard, furniture, advertising materials, building decoration materials inner decorative

materials for car, train and steamship. decoration materials for car,train and steamship.

4.This product is light,storage transport.construction are rather convenient

This product can be worked with normal tools for wooden material

Driling,sewing,nail,planing,bonding can be conducted like wooden material

It is suitable for thermal shaping,thermal bending and fold processing

It can be welded.it can also be bonded with other PVC material

The surface of this product is smooth,it can be printed (Clean the surface before printing)

5.Transportation:such as steamship, airplane, carriage, traine compartment, roof shed, case core layer, inner

upholster, etc.

6.Advertisement:such as screen printing, computer lettering, ad board, etc.

Industry:such as chemical industry antisepticizing project, thermoforming for refrigeratroy, for temperature keeping,

for environment protection, etc.


Applications:

1.field:outdoor,building,logistic,car,garden,home decoration,

2.product:plank floor,pavilion,chair,door,building template,tray,rail crosstie,fence,courtyard handrail,flower pot.

3.decoration

4.green environment protection, waterproof, damp proof, anti-corrosion, rot-resistence, ametabolic and good

fire-retardant

5.The machine also include the die head, cooling calibrating mould, cooling carrying roller,hauling-off unit,edge

trimming device,dust collecting machine,cutting device,and delivery stacker.

6.main export place:north America,africa,Europe,southeast asia,south America,etc

7. Available in different colors and wood grain design

8.Material is 100% recycled.



Specifications:

Production line&Auxiliary machines:

Part a: PVC/WPC crust/celuka/skinning foam board/sheet production line
NO. Machine name Type Qty. Note
1 Conical twin screw extruder SJSZ80/156 1set with spring up loader
2 Electric control system   1set Siemens electrical parts
3 T-mould   1set JC Times(China NO.1 brand)
4 Calibration unit   1set 4pairs with size:1500*600*100mm
5 Cooling bracket device   1set 5000mm(length)*1500mm(width)
6 Haul-off device   1set 8paris
7 Shearing unit in length and width   1set Siemens motor
8 Dust vacuuming unit   1set China top brand
9 Stacker   1set 2500mm*1750mm



Competitive Advantage:

1.good after-service

2.spare parts are free

3.guarantee:one year or according to customer’s requirement.

4.advanced technology and best quality

5.international certification standard.

6.our engineer help and teach customer to test the machine.
