Faux Marble Wood Plastic Composite Extrusion Line , WPC Marble Board Plastic Extruder

Faux Marble Wood Plastic Composite Extrusion Line , WPC Marble Board Plastic Extruder
Faux Marble Wood Plastic Composite Extrusion Line , WPC Marble Board Plastic Extruder

Large Image :  Faux Marble Wood Plastic Composite Extrusion Line , WPC Marble Board Plastic Extruder

Product Details:
Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE UL CSA ISO9001
Model Number: SJSZ65/132
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per quarter

Faux Marble Wood Plastic Composite Extrusion Line , WPC Marble Board Plastic Extruder

Description
Screw Type: Double Screw Output: Accoridng To Customer's Requirement
Product Type: Board Certificate: CE
Field: America,africa,europe,etc Model: Different Kinds
High Light:

WPC Extrusion Line

,

Wood Plastic Production Line

Faux Marble Wood Plastic Composite Extrusion Line , WPC Marble Board Plastic Extruder


Quick detail:

1. Stable running extruder
2. Well designed mould
3. Efficient cooling system


Description:

 These products are mainly applied for making pallets, packing cases, floors, wall decoration materials and other wide applications. The wood powder or plant fiber can be put up to max. 50-75%. This machine can produce the PP, PE, PVC, ABS, PS and etc

Exterior dimension: Lx W x H: 6000x1100x1000mm (adjustable)
Vacuum pump: 4x5.5KW,Water pump: 2×4KW;   Origin: Made in qingdao, China
Three direction adjustment:Forward and Backward with 0.75 Kw motor,Range: ±1000mm
Up and down, left and right manually adjusted;Range: up and down±150mm

 Haul-off and cutter (combined)
 Haul-off speed: 0-3m/min;Motor power: 5.5KW; Caterpillar width: 210mm;
Caterpillar length: 2200mm;Pneumatic clamp;
Cutter:Motor power: 2.2KW;Scrap collecting motor power: 1.5KW;Diameter of saw: 500mm;
Cutting range: 200mm;With scrap collecting device;

 Mould -accoring to customer sample or drawing

the mould  (one mould can produce two pcs ) , the line speed is 4m-8m/min ( one pcs )
We give you high speed mould and best mould material 3Cr17 ! we also give you good engineer serive in your factory and best forumal for free .



Applications:


1.Optimized design and delicately made screw and barrel results in excellent plasticity.
2.Advanced electric control system, subsection failure alarm, easily for trouble-shooting.
3.High performance distribution system for torque deceleration enhanced the durability and easy for maintenance.
4.Perfect and accurate temperature control system ensures steady output



Specifications:


Model

SJSZ65/132,SJSZ80/156,SJSZ92/188

usage

extrusion outdoor decorative

raw material

recycled PE/PP,wood powder, additive material,etc

product size

maximum:400mm,or according to prdroduct’s drawing

Extruder feature

Special designed extruder

wood powder ( wood fiber)

high volume of addition up to 50~75 percent

Plastic proceed

PP,PE,PVC,wood plastic composite

Auxiliary machine

Emboss machine,sanding machine,polishing machine

Product type

Dustbin, Sound insulation board
(wall),edging,blinds,bulkhead,curtain rod,



Competitive Advantage:
1.We can make and manufacture products according to customer specific needs.
2.Provide best and professional service for you, please contact with us freely.
3.For more information, please contact us at any time.
4.Stable performance, best price, good quality , good after-sales service.
