Product Details:
|
| Power: | 11-125KW | Capacity: | 300kg/h |
|---|---|---|---|
| Type: | Plastic Production Line, Plastic Extrusion Line | Screw Design: | Single Screw |
| Process: | Extrusion | Application: | Conduit,etc |
| High Light: | plastic extruder machine,plastic production line |
||
Conduit Pipe Plastic Extrusion Line Anti - Corrosion for Washing Machine
Quick detail:
1. widely used in fields of circuit of machine tool,tubes of air conditioner and washing machine, etc
2. water circulating cooling and air cooling
Description:
This line consists of extruder, mould, moulding machine, air cooling unit , coiler, which can continually extrude corrugated pipes in different sizes.
Moulding unit adopts excellent steel modules, through heat processing, good wearability and high reliability, which ensures the hardness and precision of the modules; together with special gears make the modules more stable in performance.
Configurations:
Specifications:
|
Diameter Scope |
4.5-9 |
9-32 |
32-50 |
|
Main Extruder |
SJ-30 |
SJ-45 |
SJ-65 |
|
L/D |
30:1 |
30:1 |
30:1 |
|
Output kg/h |
10 |
40 |
80 |
|
Main Motor Power kw |
4 |
11 |
18.5 |
|
Corrugator Power kw |
1.1 |
1.5 |
1.5 |
|
Mould Block Pairs |
42 |
44 |
44 |
|
Cooling Type |
Water and air cooling |
||
|
Linear Speed (m/min) |
6-10 |
8-12 |
8-15 |
|
Counting Type |
Sensing counting |
||
|
Winding Type |
Automatic/Manual |
||
Applications:
1. high-temperature resistance
2. Used as wire and cable passing pipe,washing machine drain pipe,dust collector pipe and ventiduct
3. resistant to corrosion and abrasion, high intensity, good flexibility, etc
Competitive Advantage:
1. Low water consumption
2. ISO,CE
