Product Details:
|
| Model Number: | SJ-90/33 | Condition: | New |
|---|---|---|---|
| Dimension(L*W*H): | According To Model | Raw Material: | PE / PPR / PERT |
| Place Of Origin: | Shandong , China | Pipe Diameter: | 20-160mm |
| Dimension: | According To Model | Voltage: | 380v50hz |
| High Light: | Plastic Extrusion Equipment,Plastic Extruder Machine |
||
Durable One Screw Cool and Hot Water Pipe Cutting Machine low noise
Quick detail
1. Raw material + additive → mixing → vacuum feeding machine → hopper dryer → single screw extruder → color code extruder → mould and calibrator → vacuum forming machine → cooling tank → haul off machine → cutting machine → stacker
2. HDPE/PPR/LDPE series plastic pipe extrusion line is mainly used in the area of agricultural water supply, architectural water supply, gas supply and transportation, telecommunication cables etc. This line has the advantages of easy operation, high automatic degree, stable and reliable production, well received by customers.
Description:
1. Special single screw extruder for polyolefin , having high extruding velocity and effective plasticization. separation mixing screw specialized for polyolefin. specially designed 2-3 co-extruding die , reasonable channel , smooth outside and inside wall , and little internal stress. producing pipe limit 20-160mm , manufacture velocity up to 15m/min. may be used to produce HDPE silicon core tube , ordinary PP-R , PE , PEX and PE-RT pipes.
2. PE pipe extruder machine line : consists mainly of twin conical (parallel) screws extruder, vacuum calibrating tank, haul-off unit, cutting unit, tilter, etc.The raw material is pvc powder. As the granule material, such as, PE, PP, PPR, etc. they would need single screw extruder. other downstream equipment, are similar with pvc pipe production line as above.
3. PPR Pipe Extrusion Machine/ppr pipe extusion line can also be equipped with length-measuring and thickness increasing instruments . this line is characterized of reliable performance and high production efficiency . anti-noise spiral pipe and foam core pipe production lines are also available according to customers requirement.
Main Technical Parameters
| Extruder | SJ-65/30B | SJ-90/30B | SJ-120/30B | SJ-150/30B |
| SJ-30/25B | SJ-45/30B | |||
| SJ-25/25B | SJ-25/25B | SJ-25/25B | SJ-25/25B | |
| Pipe Dia(mm) | 20-63 | 20-160 | 110-400 | 315-630 |
| Water Sizing Trough | SGZL-75 | SGZL-160 | SGZL-400 | SGZL-630 |
| Water Cooling Trough | SGPL-75 | SGPL-160 | SGPL-400 | SGPL-630 |
| Haul-off Machine | STG-75B | SLQ-160B | SLQ-400B | SLQ-630B |
| Cutting Mchine | STG-75 | STG-160 | STG-400 | STG-630 |
| Stacker | FZ-6000 | FZ-6000 | FZ-6000 | FZ-6000 |
Application:
1. PE Pipe Machine is mainly used in agricultural water supply system, PE eletric pipe, architectural water supply system, pavement of cables
2. can be directly used in purfied water drinking water supply system. Central air condition system'
Adopts co-extrusion die head and adds marking line for pipes.
Why choose us:
1. We have more than 15 years experiences
2. our plastic machine have widely application
3. engineers availiable to service
