Product Details:
|
| Brand Name: | Aorui | Automatic Grade: | Fully Automatic |
|---|---|---|---|
| Certificate: | CE ISO9001 | Temperature Controller: | Omron |
| Place Of Original: | Shandong , China | Motor: | Siemens |
| Machine Color: | According To Customer's Requirement | ||
| High Light: | Plastic Extruding Machine,Plastic Extruder Machine |
||
Hot Water PPR Pipe Making Machine , PPR Pipe Extrusion Line , PPR PERT Pipe Machine
Quick detail
1. Production Set PP-R &PE-RT, a complete line for cold/hot water pipes manufacture, is mainly used to produce industrial pipes for water and compressed air transportation. The pipes diameter and thickness can be varied. PP-R is an updated achievement in the developmenthistory of worldwide pipelines production.
2. It's designed with advanced technology includes 1st single screw extruder for square shaped pipe, square shaped pipe extrusion die, vacuum calibration water tank, spray cooling water tank. 2ND single screww extruder for melting glue material, spiral forming unit, cutting and stack unit.
Description:
1. PPR pipe extrusion making machine line is used to produce PPR and FR PPR pipes for cold and hot water supply in hose, it's new product which has huge demand and increasing. We also call it PPR pipe production line. PPR pipe extrusion line. PPR Pipe extrusion production line. PPR pipe extrusion machine. PPR pipe making machine. PPR pipe machine. etc...
2. PPR/ FR PPR pipe production line is mainly composed of:
1. Autoloaders and dryer,
2. Extruder
3. Vacuum calibration and cooling tank
4. Extended water cooling tank
5. Haul off machine
6. Printer(meter counting printer or ink jet printer)
7. Cutter
8. Stacker
3. Our company applies the latest oversea technology, fully display the technical superiority of the screw. The production has the features of high output, good plasticity, higher pipe pressure resistance etc. the entire extrusion line realize automatic control from the material feeding to pipe stacking. With the installation of the encoder and the PLC, the non-dust cutter could realize accurate setting length cutting. To insure the stability during high speed production, we adopt advanced basket-type die head.
Main Technical Parameters
| Model | Pipe diameter | Extruder | Vacuum calibration tank | Cooling tank | Haul-off | Cutter | ||||
| Vacuum pump | Water pump | Length(MM) | Water pump | Length(MM) | Catepiller | Motor | Cutting type | |||
| GF-63 | 16-63MM | SJ65/30 | 3KW | 3KW | 6000 | 4KW | 6000*2 | 2 | 3KW | Swarf-free cutting |
| GF-110 | 50-110MM | SJ75/33 | 4KW | 4KW | 6000 | 4KW | 6000*2 | 3 | 4KW | |
| GF-160 | 50-160MM | SJ90/33 | 5.5KW | 5.5KW | 6000 | 4KW | 6000*2 | 3 | 5.5KW | |
Applications of PPR, PE-RT pipes:
PPR, PE-RT plastic pipes is the key promotion environment friendly product of national ministry of construction. It has the merit of non-toxic, rustless, non-filthily, thermo stable, heat preservation, convenient installation, reasonable price and so on. It has been widely applied in the housing cold & hot water pipe.
FAQ:
Q1:Are you a trading company or a manufactory? A1:We are a manufactory,so we can give u the best service .
Q2:What's your guarantee or the warranty of the quality if we buy your machines? A2:We offer you high quality machines with 1 years guarantee . we will give you spare part free in 1 years
Q3:When can I get my machine after I paid? A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives? A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q5:How about the spare parts? A5:After we deal down all the things , we will offer you a spare parts list for your reference.
