CE Construction Template Wood Plastic Composite Extrusion Line Extruder Machine
Quick detail:
1. WPC sheet machine adopts high-efficiency conical double-screw extruder with forcible cooling system to extrude and form.
2. The wood plastic sheet out from our line has features of green environment protection, damp proof, antisepticise and not distortion, thus suitable for processing method of wood and can be recycled to reuse.
3. It has been widely used in wide door, partition panel, construction template, base plate of container, furniture panel, etc.
Description:
1. Process line of wpc foam board machine:
Raw material+wood power+additive→mixing → conical double screw extruder → sheet extrusion mould → cooling molding die → vacuum calibration tank → belt haul-off → cutter → rack → finished product inspecting&packing
2. The WPC Plate has the same characteristics as wood boards: Which can enailed , can be sawed , can be drilled , can be planed , can be sculptured. With the exclusive formula developed by our company , there is no need to granulate the material , which is cost savings and labor saving.
3. the price of wpc template board is far lower than the current construction industry to use bamboo template, and has excellent flame retardant properties, from the self-extinguishing of fire, smoke-free, without any gas. The new generation of safe green energy-saving products.
Applications:
1.Traffic and Transportation:roof,sandwich layer,inside upholstering plate for carriage of ship,plane,automobile,train,ect.
2.Construction Upholstering:wall panel outside and inside building,partition board,plate for non-dust room,plate of hung ceiling,ect.
3.Advertising:Printing,nameplate,showing plate,ect.
4.Furniture:kitchen,washing room,indoor decorative material,ect.
5.others:template,exercise equipment,material for feeding use,water resistant facility by sea,ect.
Technical Parameters
Specifications:
| tems | Requirements |
| Product size | 1220mm width, length can cut at any length |
| Product thickness | 5-20mm (ABA three layer, B is foamed layer, A is unfoaming layer) |
| Product application | Furniture board, kitchen cabinet, construction formwork |
| Density | 0.45-0.8ton/m3 |
| Raw material | PVC+wood+caco3+chemical additives |
| Finishing surface | Laminating, hot stamping, printing, painting |
| Production capacity | 250-400kg/h |
Competitive Advantage:
