Plastic Board PVC Foam Board Machine , PVC Foamed Board Production Line

Plastic Board PVC Foam Board Machine , PVC Foamed Board Production Line

Brand Name: AORUI
Model Number: SJSZ92/188
MOQ: One set
Price: Negotiable
Payment Terms: 30% prepaid by T/T , blanced 70% by T/T or L/C before shipping
Supply Ability: 10 Sets per month
Detail Information
Place of Origin:
China
Certification:
CE UL CSA ISO9001
Certification:
CE & ISO9001
Voltage:
380V 50HZ
Company:
AORUI
Inverter:
ABB
Cooling Way:
Recycling Water
Machine Weight:
4T
Place Of Original:
Shandong , China
Screw Design:
Twin Screw
Packaging Details:
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Supply Ability:
10 Sets per month
Highlight:

Foam Sheet Extruder

,

PVC Foam Board Production Line

Product Description

Good Quality Plastic Board PVC Board Making Machine , PVC Foamed Board Production Line



Quick detail:



1. PVC Celuka foam board difference:

PVC Celuka Grade A is a kind of PVC foam boards we recommended to our customers as they have superior quality. The extrusion line adopts Celuka foam technology. These processes result in a "skinning" or outer layer of the foam board and harder or more scratch resistant.



2. Compared with other PVC foam board, this kind of PVC foam board not only has much more smooth surface, but also has the more skin hardness, and the mechanical performance of the PVC Celuka foam board is much better than other PVC foam boards.



Description:





1. Free foam board extrusion machine
This PVC free foaming board extrusion machine is composed of special twin-screw extruder, T-die head and downstream equipments. This machine has the features of high output, stable extrusion, high foaming, smooth and wearable surface etc. And also our company will supply the customer raw material formulation and whole processing technology.



2. COMPONENTS OF THIS MACHINE:
1. High speed hot and cold mixer 1 set
2. Spring feeding machine 1 set
3. Conical twin screw extruder 1 set
4. T-die head 1 set
5. Three roller calendars 1 set
6. Cooling frame and edge cutting devices 1 set
7. Haul off machine 1 set
8. Plastic cutting machine-guillotine 1 set
9. Twin position coiler 1 set
10. Plastic crusher 1 set
11. Plastic pulverizer 1 set

12. Water chiller 1 set





Main tech parameters of PVC foam board making machine



model SJSZ45 SJSZ51 SJSZ65 SJSZ80 SJSZ92
screw stem diameter(mm) 45/90 51/105 65/132 80/156 92/188
rotational speed of screw stem(r/min) 1-45 1-45.5 1-38 1-36.9 1-34.7
effective work length of screw stem(mm) 1070 1100 1440 1800 2500
main power (kw) 15 22 37 55 110
cylinder heating power(kw) 9.6 11.5 24 36 88
capacity(kg/h) 70 80 250 360 1000
central height of machine(mm) 1000 1000 1000 1000 1000
Net weight(kg) 28000 3000 4000 5000 5500









Application of pvc foam board production line



1. Wood-plastic mould can be reproduced like wood.It can be cut,planed,madea bond by glue or fastened with nalis or screws.It's easy to maintain.


2. Preserved from acid,alkali,corrosion,impervious to attacks by insects and rats,wood-plastic mould plates provide less moisture absorption.


3. The product can be recycled and degraded for environmental protection





Competitive Advantage:



  • experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology
  • Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.
  • After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
